Crompton Greaves Three Phase aluminium
- AS/ANZS 1359.5:2006 compliant
- IP55 aluminium construction
- Standard class F insulation with class B-temp rise
- Multi-mount feet
- 230/400V, 50Hz up to 3kW
- 400/690V, 50Hz 4kW and above
| Product code | kW | HP | Frame | Current (A) | Shaft (mm) |
| IMGE1006 | 0.18 | 0.25 | GD63 | 0.53 | 11 |
| IMGE1009 | 0.25 | 0.33 | GD63 | 0.62 | 11 |
| IMGE1012 | 0.37 | 0.5 | GD71 | 0.83 | 14 |
| IMGE1015 | 0.55 | 0.75 | GD71 | 1.14 | 14 |
| IMGE1018 | 0.75 | 1 | GD80 | 1.57 | 19 |
| IMGE1021 | 1.1 | 1.5 | GD80 | 2.22 | 19 |
| IMGE1027 | 1.5 | 2 | GD90S | 3 | 24 |
| IMGE1036 | 2.2 | 3 | GD90L | 4.12 | 24 |
| IMGE1042 | 3 | 4 | GD100L | 5.3 | 28 |
| IMGE1051 | 4 | 5.5 | GD112M | 7.3 | 28 |
| IMGE1057 | 5.5 | 7.5 | GD132S | 10.19 | 38 |
| IMGE1063 | 7.5 | 10 | GD132S | 12.6 | 38 |
| Product code | kW | Hp | Frame | Current (A) | Shaft (mm) |
| IMGE1099 | 0.18 | 0.25 | GD63 | 0.56 | 11 |
| IMGE1102 | 0.25 | 0.33 | GD71 | 0.72 | 14 |
| IMGE1105 | 0.37 | 0.5 | GD71 | 1 | 14 |
| IMGE1111 | 0.55 | 0.75 | GD80 | 1.43 | 19 |
| IMGE1114 | 0.75 | 1 | GD80 | 1.72 | 19 |
| IMGE1117 | 1.1 | 1.5 | GD90S | 2.44 | 24 |
| IMGE1123 | 1.5 | 2 | GD90L | 3.21 | 24 |
| IMGE1129 | 2.2 | 3 | GD100L | 4.42 | 28 |
| IMGE1132 | 3 | 4 | GD100L | 6.8 | 28 |
| IMGE1138 | 4 | 5.5 | GD112M | 8.7 | 28 |
| IMGE1144 | 5.5 | 7.5 | GD132S | 10.31 | 38 |
| IMGE1147 | 7.5 | 10 | GD132M | 13.84 | 38 |
| Product code | kW | Hp | Frame | Current (A) | Shaft (mm) |
| IMGE1177 | 0.18 | 0.25 | GD71 | 0.65 | 14 |
| IMGE1180 | 0.25 | 0.33 | GD71 | 0.91 | 14 |
| IMGE1183 | 0.37 | 0.5 | GD80 | 1.12 | 19 |
| IMGE1186 | 0.55 | 0.75 | GD80 | 1.58 | 19 |
| IMGE1189 | 0.75 | 1 | GD90S | 1.92 | 24 |
| IMGE1198 | 2.2 | 3 | GD112M | 5.04 | 28 |
| IMGE1201 | 3 | 4 | GD132S | 7.3 | 38 |
| IMGE1204 | 4 | 5.5 | GD132M | 9.3 | 38 |
| IMGE1207 | 5.5 | 7.5 | GD132M | 11.56 | 38 |
| Product code | kW | Hp | Frame | Current (A) | Shaft (mm) |
| IMGE1231 | 0.25 | 0.33 | GD80 | 1.2 | 19 |
| IMGE1234 | 0.37 | 0.5 | GD90S | 1.63 | 24 |
| IMGE1237 | 0.55 | 0.75 | GD90L | 2.3 | 24 |
| IMGE1240 | 0.75 | 1 | GD100L | 2.64 | 28 |
| IMGE1243 | 1.1 | 1.5 | GD100L | 3.7 | 28 |
| IMGE1246 | 1.5 | 2 | GD112M | 4.4 | 28 |
| IMGE1249 | 2.2 | 3 | GD132S | 5.9 | 38 |
| IMGE1252 | 3 | 4 | GD132M | 7.8 | 38 |
